Features :
Window base user friendly software operates on personal computer.
Programmable 9 axis CNC controller with for engraving, dulling and cutout of various design as well as side cutting with vertical and horizontal head respectively compatible with corel draw for designing.
Variable spindle speed for horizontal and vertical.
Automatic zero search of all Axis (homing).
Linear and circular programmable interpolation.
Horizontal 10 tools and vertical 10 tools programmable with variable depth and spindle speed.
Machine is totally operated on single phase power supply. Air conditioning required. Machine works under normal room temperature.
All required axis are fitted with ball screws.
Facilitated with manual lubricating pump.
No special programming required for different diameters of bangle and ring.
Designing can be placed wherever needed on the width of work piece either circular or widthwise.
Effective “auto electro brake system” which stops horizontal/vertical spindle instantly.
Machine is encased in a very attractive cabinet having true glass sliding doors to collect scrap and prevent outside dust.
Machine is provide with vacuum dust collector.
Special high speed precision spindle is supplied on request.
case of power failure design can be continued from any point and complete machine is supported with UPS.
Specifications
Machine Dimension : 36 X 51 X 72 inches
Machine Weight : 1000 KGS
Additional Information
Product Code : UBEFMAS9
Payment Terms : L/C, D/A, D/P, T/T
